Description
We improve your everyday life…
Through SOPRO’s extensive experience in digital sensors, the SOPIX® series improve your everyday life by simplifying use and bringing you exceptional image quality. Our sensors have been developed to satisfy all requirements of any dental practice while offering a solution for every budget.
Integrated in all SOPIX series sensors, patented by SOPRO, freezes the image during
acquisition, in order to protect each image from overexposure. The first shot is always perfect, the images always clear.
Fast and easy
The SOPIX series sensors, available in two sizes, are always ready to acquire. Your images are displayed instantaneously.
Better patient comfort
Edges and corners are rounded on the sensor to improve patient comfort.
High-quality images
The SOPIX series sensors provide accurate images and striking contrasts to ensure a reliable diagnosis.
Smart design
White side stripes offer high visibility of the sensor in the darkness of the mouth. They assist the dental professional in correctly positioning the X-ray tube perpendicular to the sensor. The images are accurate, without distortion.
TECHNICAL SPECIFICATIONS:Sensor Size 1
External dimensions-25 x 39,5 mm
Active surface area-600 mm2 (20 x 30 mm)
Number of pixels-1,25 million
Pixel size-22µm x 22µmSensor technology:
CCD and scintillator
True resolution-20 pl/mm
Theoretical resolution-22,7 pl/mm
Sensor cable length-2,00 m
Controller:
Technology-DSP 32 bits
Connection-USB 1.1 and USB 2.0
Image acquisition in 4096 gray scales
Cable length-5 m
Image processing software
Minimum configuration required:
500 MHz Pentium III
128 MB RAM
20 GB hard disk
2 USB ports
Operating System: Windows 98 SE, 2000 Pro and XP SP1 and above
Monitor resolution: 1024 x 768 and above
Recommended configuration:
1.8 GHz Pentium IV
256 MB RAM
40 GB hard disk
4 USB ports
Operating System: Windows XP Pro SP1 and above
