Description
Tuttnauer EZ11 Plus Fully Automatic Autoclave is equipped with just as many premium features as the EZ9Plus, but with a larger chamber size. An innovative EZView multi-color display gives users a bright, active viewing area. With dynamic air removal technology and closed-door drying, the EZ11Plus sterilizer includes top-of-the-line sterility and efficiency. Along with quick and safe drying, the EZ11Plus also includes a network port and USB port for all of your data monitoring needs.
Tuttnauer EZ11 Plus designed to meet the most current sterilization standards ANSI/AAMI ST55, helps practitioners meet today’s challenging workloads and regulatory requirements. The Tuttnauer EZ11Plus automatic Autoclave with an 11” chamber size and 5 large trays offers versatile loading options to handle large volume loads, friendly EZGlide door features a sleek modern look and effortless opening and closing.
The EZ11 Plus model boasts several key features, including the newly designed EZGlide self-locking door, which is ergonomically friendly and can be opened and closed effortlessly. The EZView multicolor display screen is easy to read, even from a distance. If a cycle is not running, the operator can scroll through the EZPad keys —while the door is open— to select a program and review all program parameters.
During a running cycle, EZView shows not only the actual temperature and pressure in the chamber but also each stage of the cycle. As the color wheel moves, the colors change for each stage. The convenient EZFill water reservoir can be filled with distilled water from either the top of the unit or through the front-fill funnel located inside the door.
Tuttnauer EZ11 Plus Features
- The newly designed, ergonomically friendly EZGlide door features a sleek modern look and effortless opening and closing.
- Innovative EZView Multi-Color Display offers real-time cycle information that is easy to read, even from a distance. The EZView displays cycle parameters, temperature, and pressure in the chamber. During a cycle, each stage is displayed with an active color wheel and text.
- Closed-door drying, meaning the door remains closed through the dry cycle to maintain sterility and ensure efficient drying. A high-efficiency air pump circulates filtered air through the chamber for fast drying. 0.2 HEPA filter (replaceable).
- Comprehensive 2-year parts & labor warranty and 10-year chamber warranty.
- 11″ diameter X 19.8″ deep chamber and flexible loading options. The exceptionally deep 19.8 chamber works in a variety of loading options to suit any office:
- Use the 5 full-sized trays for packs/pouches
- Use the tray rack (included) to accommodate 4 full plus 4 half-sized cassettes no additional cassette rack to buy!
- Use the optional Tuttnauer pouch rack (model AR910) to encourage proper loading. One pouch rack is included with each EZ11Plus.
- Front or top water fill options: accessible EZFill front or top water fill option to enable easier filling of the reservoir.
- USB Port enables users to easily transfer cycle data via a flash drive to a PC.
- Network Port allows for connection to a local network to provide remote monitoring of the system when used with optional RPCR Software. The network port is located in the rear of the unit.
- Dynamic Air Removal Technology to effectively remove air from the chamber.
- Designed to meet the most current sterilization standards ANSI/AAMI ST55.
- Optional printer documents a detailed history of each cycle.
Tuttnauer EZ11 Plus Autoclave Specifications
Dimensions
- Height: 17.3 in (440 mm)
- Width: 20.9 in ( 530 mm)
- Depth: 24.8 in ( 630 mm)
- Weight: 122 lbs (56kg)
Chamber Dimensions
- 11in x 19.8 in ( 230 mm x x504 mm)
- Chamber Volume 7.5 gal – 28.5 liters
- Tray Dimensions
- Height: 0.6 in (16 mm)
- Wight: 6.7 in (169 mm)
- Depth: 16.3 in ( 413 mm)
- No. of trays: 5
Power
- Current: 1400 W – 12 A
- Voltage – Frequency: 120v – 50/60 Hz
Included:
- Trays: 5 large trays plus 1 pouch rack.
- Cassettes: 4 full-size standards plus 4 half-sized standard cassettes (the included tray rack is rotated 90°)
- Tray handle for removing hot trays.
- Pouch rack for standing pouches.
- Heating Element Located outside the chamber to maximize sterilization capacity.
- Drying: Air-assisted drying starts automatically with the door closed, this maintains sterility and ensures efficient drying.
- Automatic-Self Locking door system.
- Cycle History: 100 cycles that can be stored for reprinting or downloading to PC
- Custom Cycles: 2 built-in full access custom cycles and up to 20 more possible. Extreme customization is possible.
- LCD informs the user when a simple maintenance check is necessary (programmable setting)
- Printer.
- The EZllPlus
- Power cord
- Five instrument trays
- Rack for instrument trays, doubles as the cassette rack
- One cassette handling tool
- Package of Chamberbrite Clean and Shine autoclave cleaner
- Drain tube
- Extra door gasket
- Extra fuses
- Operators manual
- Log-book
- Calibration report
- Operation and maintenance
- Laminated operating instructions
